Item |
Specification |
|
Dimensions (H × W × D) |
44 × 294 × 179 mm (1.73 × 11.57 × 7.05 in) |
|
Ports |
24 × 10/100/1000BASE-T copper ports (2 uplink ports) |
|
Operating mode |
Standard Isolation Aggregation Clone |
|
MAC address entries |
8K |
|
Switching capacity |
48 Gbps |
|
Forwarding capacity |
35.7 Mpps |
|
Packet caching |
4 Mbit |
|
Switching mode |
Store-and-forward switching |
|
Power |
100 to 240 V AC |
|
Auto-MDI/MDIX |
Yes |
|
Cooling method |
Natural cooling |
|
Operating temperature/storage temperature |
0°C to 40°C (32°F to 104°F)/–40°C to +70°C (–40°F to +158°F) |
|
Operating humidity/storage humidity |
5% to 95% RH, noncondensing |
|
Certifications |
CE,RoHS |
|
MTBF |
> 50000 H |
|
Installation method |
Rack-mount by using mounting brackets |
