Computing |
Up to 4 Intel® Xeon® Processor Scalable Platinum/Gold Family, 4/6/8/10/12/14/16/18/20/22/24/26/28 Cores, Maximum Support of 205W |
|
Memory |
Up to 48 DDR4 memory, Maximum support 2666MT/s, support RDIMM or LRDIMM, maximum capacity of 6TB |
|
Storage Controller |
Standard Array controller supports SATA RAID 0/1/10/5 Optional HBA card on Array card slot, support SATA/SAS RAID 0/1/10 Optional Array card on Array card-specific slot, support RAID 0/1/10/5/6/50/60/1E/Simple Volume Optional standard PCIe 3.0 HBA and Smart Array card |
|
FBWC |
Support up to 2GB DDR3-1,866 MHz, 72-bit wide bus at 14.9 GB/s IO Performance |
|
Local Storage |
Supports SAS/SATA HDD/SSD; Maximum 48SFF front mounted drive Supports a maximum of 16 NVMe, supports PCIe M.2 options |
|
Network |
Embedded 1Gbps HDM management network port; Optional 4×1GE electrical ports, 2×10GE Electrical Ports, 2×10GE optical ports through mLOM, mLOM Supports NCSI function, optional standard PCIE 3.0 network adapter options |
|
Expansion Slots |
Upto 20 PCIe 3.0 slots (18 rear standard slots, 2 front, supports GPU) |
|
Ports |
Optional front VGA, standard rear VGA, serial port, 4 USB 3.0 (1 front, 2 rear, 1 built-in), 2 USB 2.0 (2 front) |
|
GPU Support |
Support 2 double wide GPU options upto 10.5” |
|
CD-ROM |
Supports external CD-ROM drive |
|
Management |
HDM agentless management tools (with independent management port) and H3C FIST management software |
|
Power & Cooling |
Optional Platinum Level 800W/1200W/1600W Optional Platinum Level 800W 336VHDC N+N redundant power supply Passed 80 Plus certification, up to 96% energy efficiency conversion rate Support hot-swappable redundant fans |
|
Certification |
Support CCC, CECP, SEPA Certification |
|
Operating Temperature |
5℃～45℃ |
|
Shape/ Chassis dimensions |
4U 174.8mm(H)*444mm(W)* 807.4mm(D) (without safety panel) |
|
Warranty |
3-year 5*9 Next Business Day Warranty |
